WZ20-28 Backhoe Loader
- 12-Month Warranty
- Factory Direct Price
- Fast Global Shipping
- 24/7 WhatsApp Support
Operating Weight: 5.4 t
Dimensions: 6.2 × 1.96 × 2.8 m
Power: 78 kW
Product Details
WZ20-28 5.4-Ton 4WD Backhoe Loader
The WZ20-28 backhoe loader combines a 2.5-ton front loader, 3.5 m dumping height and 2.6 m digging depth. Powered by a 78 kW turbocharged diesel engine, its 4WD drivetrain and articulated steering support material loading, trenching and utility construction.
Technical Specifications
| Model | WZ20-28 |
| Operating Weight | 5,400 kg |
| Engine Power | 78 kW Turbo Diesel |
| Loader Rated Load | 2,500 kg |
| Loader Bucket | 1.25 m³ |
| Max. Dump Height | 3,500 mm |
| Max. Digging Depth | 2,600 mm |
| Backhoe Bucket | 0.2 m³ |
View Full Specifications▾
| Dimensions | 6,200 × 1,960 × 2,800 mm |
| Travel Speed | 30 km/h |
| Turning Radius | 4,500 mm |
| Transmission | Automatic / 2F + 2R |
| Tire Size | 16/70-20 |
| Hydraulic Pressure | 20 MPa |
| Loader Breakout Force | 42 kN |
| Backhoe Digging Force | 28 kN |
| Max. Digging Radius | 4,600 mm |
| Backhoe Swing Angle | 180° |
Equipment & Attachments
Machine Configuration: Four-cylinder turbocharged diesel engine, articulated hydraulic steering, large hub-reduction 4WD axles, 2F+2R automatic transmission, air brakes and a 180° backhoe swing range.
Attachment Options: Contact us to confirm compatible loader buckets, backhoe buckets and other available work attachments.
Get a WZ20-28 Backhoe Loader Quote
Request WZ20-28 pricing and FOB/CIF quotations for your destination port.
Choose one machine or multiple units and ask about available attachments and configurations.
Contact us via WhatsApp or the inquiry form. Share your country, quantity and intended application for a tailored offer.
Key Advantages
1. High-Dump Front Loader: A 3.5 m dumping height and 1.25 m³ bucket support loading materials into elevated truck bodies.
2. Combined Loading & Excavation: A 2.5-ton rated loader and 2.6 m digging depth cover material handling, trenching and backfilling.
3. Articulated 4WD Mobility: Hydraulic steering and hub-reduction axles support maneuvering on construction and municipal worksites.
Applications
Road & Municipal Works: Roadside trenching, drainage excavation and backfilling.
Material Loading: Handling soil, sand and aggregates on construction sites.
Utility Construction: Pipeline trenches, foundation excavation and site preparation.
Note: Confirm final machine configuration, attachment compatibility and shipping details before ordering.
